Bosch GCM 10 MX Slide Mitre Saw spare parts

    Tool number 3 601 M29 0F0 · 230 V

    Prices from the Bosch India Spare Parts Price List 2026 · Last updated

    View the Bosch GCM 10 MX →
    Call +91 95123 49969WhatsApp a parts list

    Most replaced parts

    1 619 PA6 835

    ₹2,979

    Field 220-240V

    1 619 PA6 703

    ₹580

    Switch

    1 619 PB5 138

    On request

    Power supply cord

    1 619 PA6 959

    ₹1,204

    Bearing Block

    1 619 PA6 980

    ₹580

    Helical Gear

    1 619 PA7 056

    ₹4,939

    Armature 220-240V

    1 619 PA7 057

    ₹833

    Carbon-Brush Set

    1 619 PA7 032

    ₹608

    Spindle

    All parts

    ItemPart numberDescriptionQtyList price
    Motor Housing1₹1,318
    Insert1₹162
    1 619 PA6 835Field 220-240VWear part1₹2,979
    Countersunk-Head Screw4₹68
    1 619 PA6 703SwitchWear part1₹580
    Nut1₹68
    1 619 PB5 138Power supply cordWear part1On request
    Pointer1₹46
    Grommet1₹68
    Nut1₹46
    Fastening Clamp1₹46
    Set screw1₹68
    Suppression Capacitor1₹95
    Pivot Shaft1₹92
    Brush Holder2₹283
    Self-locking nut1₹46
    Pan head screw4₹162
    Scale1₹46
    Mitre Fence1₹591
    Guard Plate1₹183
    Mitre Fence1₹1,297
    Torsion Spring1₹46
    Wing Screw1₹46
    Special Screw1₹46
    Set screw2₹46
    Protective Cover1₹591
    Plain Washer4₹41
    Guard Plate1₹68
    Hex Socket Head Cap4₹94
    Special Screw1₹68
    Table1₹3,053
    Bushing1₹46
    Pan head screw2₹46
    Linkage1₹236
    Spring Washer4₹46
    Bushing2₹68
    Plain Washer6₹68
    Plain Washer2₹46
    Cover1₹46
    Pan head screw1₹46
    Knob1₹248
    Special Screw1₹46
    Spring Washer4₹68
    1 619 PA6 959Bearing BlockWear part1₹1,204
    Plain Washer1₹46
    Plain Washer2₹46
    Self-locking nut1₹46
    Self-locking nut1₹46
    Locking nut1₹95
    Bushing1₹46
    Lever1₹95
    Hex Screw1₹46
    Hex Screw3₹95
    Spacer Pin1₹46
    Base1₹3,833
    Set screw1₹46
    Sliding Plate3₹183
    Nut1₹46
    Plain Washer3₹46
    Hex Screw1₹46
    Spring Washer1₹46
    Rubber Ring1₹70
    Pan head screw2₹46
    Air-Deflector Ring1₹95
    Detent Pin1₹68
    Pan head screw2₹162
    O-Ring1₹46
    Handle1₹490
    Pivot Shaft1₹162
    shaft lock1₹95
    Scale1₹94
    Trigger1₹97
    Bolt1₹32
    Pan head screw2₹46
    Set screw1₹46
    Brush-Cover2₹46
    Clamping Flange1₹169
    Pan head screw7₹46
    Nut1₹46
    Plain Washer9₹46
    Pan head screw2₹46
    Set screw2₹46
    1 619 PA6 976Bearing coverWear part1₹68
    Compression Spring1₹46
    1 619 PA6 980Helical GearWear part1₹580
    Torsion Spring1₹46
    Pan head screw1₹46
    Locking Lever1₹162
    Spring retaining ring1₹46
    Special Screw1₹46
    Dust Separator1₹46
    Compression Spring1₹490
    1 619 PA6 984Needle bearingWear part1₹97
    Spring Holder1₹68
    Safety Guard1₹2,493
    Positioning Pin1₹46
    Angle Plate1₹162
    Extension Stand2₹608
    Spring Washer5₹46
    1 619 PA7 056Armature 220-240VWear part1₹4,939
    Hex Socket Head Cap3₹46
    1 619 PA7 057Carbon-Brush SetWear part1₹833
    Locking Plate1₹46
    Special Screw1₹46
    Bracket1₹94
    1 619 PA7 032SpindleWear part1₹608
    Push rod1₹68
    Locking Bar1₹68
    Locking pin1₹95
    Compression Spring1₹46
    Plug Connector1₹68
    Bushing1₹46
    Parallel Key1₹46
    Clamping Flange1₹242
    Rivet4₹46
    Spring Washer1₹46
    Pan head screw2₹46
    Holder1₹46
    Plain Washer1₹46
    Spacer1₹47
    1 619 PA7 031Cable SetWear part1₹162
    Hexagon Socket Wrench1₹95
    Clamp1₹490
    Support Plate1₹162
    Dust Bag1₹290

    List prices are from the Bosch India spare parts price list 2026 and may change without notice. Call to confirm the price and stock before ordering.

    Questions

    What is the field (stator) part number for the Bosch GCM 10 MX?

    Field 220-240V, Bosch part number 1 619 PA6 835 (diagram item 2). List price ₹2,979.

    What is the switch part number for the Bosch GCM 10 MX?

    Switch, Bosch part number 1 619 PA6 703 (diagram item 4). List price ₹580.

    Which power cord fits the Bosch GCM 10 MX?

    Power supply cord, Bosch part number 1 619 PB5 138 (diagram item 5).

    Which bearings does the Bosch GCM 10 MX use?

    Bearing Block, Bosch part number 1 619 PA6 959 (diagram item 59). List price ₹1,204.

    What is the gear set part number for the Bosch GCM 10 MX?

    Helical Gear, Bosch part number 1 619 PA6 980 (diagram item 84). List price ₹580.

    What is the armature part number for the Bosch GCM 10 MX?

    Armature 220-240V, Bosch part number 1 619 PA7 056 (diagram item 803). List price ₹4,939.
