Bosch GBM 50-2 Drill spare parts

    Tool number 3 601 AB4 0F0 · 230 V

    Prices from the Bosch India Spare Parts Price List 2026 · Last updated

    View the Bosch GBM 50-2 →
    Call +91 95123 49969WhatsApp a parts list

    Most replaced parts

    1 619 PB4 148

    ₹78

    Connector Cable

    1 619 PB4 201

    ₹3,501

    Field assembly 220V

    1 619 PB3 666

    ₹4,753

    Armature assembly 220V

    1 619 PB3 652

    ₹1,515

    Toothed Gear

    1 619 PB4 074

    ₹3,023

    Printed Circuit Board

    1 619 PB3 639

    ₹1,818

    Drilling Spindle

    1 619 PB3 755

    ₹758

    On-Off Switch

    1 619 PB4 295

    ₹511.5

    Carbon-Brush Set

    All parts

    ItemPart numberDescriptionQtyList price
    Motor Housing1₹2,273
    1 619 PB4 148Connector CableWear part1₹78
    1 619 PB4 201Field assembly 220VWear part1₹3,501
    Rubber Ring1₹77
    1 619 PB3 666Armature assembly 220VWear part1₹4,753
    Air-Deflector Ring1₹58
    1 619 PB4 767Power supply cord INWear part1₹6,059
    Tapping Screw2₹77
    Nameplate1On request
    Flat Seal Ring1₹89
    Manufacturer's nameplate1On request
    Oil Separator1₹123
    Brush Holder2₹376
    Straight Pin1₹77
    Housing Cover1₹758
    Tapping Screw4₹77
    Protective Cover1₹85
    Retaining ring1₹77
    Cap1₹81
    1 619 PB3 652Toothed GearWear part1₹1,515
    Cap1₹78
    1 619 PB3 651Toothed GearWear part1₹1,515
    Tapping Screw4₹40
    Toothed rack1₹1,062
    1 619 PB4 074Printed Circuit BoardWear part1₹3,023
    Parallel Key1₹77
    Fastening Clamp1₹58
    Retaining ring1₹77
    Indicator Light1₹78
    1 619 PB3 655Toothed GearWear part1₹1,515
    Tapping Screw2₹40
    Parallel Key1₹100
    Stop Block1₹78
    1 619 PB3 639Drilling SpindleWear part1₹1,818
    Shaped Spring1₹58
    O-Ring1₹78
    Potentiometer1₹186
    Shift-Lever Knob1₹316
    Clamping bracket1₹38
    Spring1₹77
    Handwheel1₹323
    Block1₹78
    Connector1₹245
    Guide Block1₹4,103
    Rear Plate1₹238
    Toothed rack1₹1,213
    Tapping Screw13₹77
    Screw2₹77
    Washer2₹77
    Screw2₹77
    Screw1₹77
    1 619 PB3 755On-Off SwitchWear part1₹758
    Countersunk-Head Screw6₹77
    Warning Label1On request
    Holding Plate2₹153
    Guide Bar2₹985
    Screw22₹77
    Headless Screw4₹77
    Spring Sleeve1₹77
    Stop Plate2₹58
    Frame1₹7,572
    Protection Sleeve1₹77
    Carrying Handle1₹161
    Protection Sleeve1₹58
    Carrying Handle1₹158
    Magnetic Base1₹12,850
    Tapping Screw8₹77
    Spring Washer4₹77
    Lifting Bracket1₹121
    Screw4₹77
    Countersunk-Head Screw6₹77
    1 619 PB4 118Control UnitWear part1₹13,552
    Flange Bushing2₹58
    1 619 PB4 119Switch UnitWear part1₹9,917
    Shaft Coupling1₹2,273
    Cover1₹78
    Scale Ring1₹78
    Indicator Lamp1₹2,415
    Handle3₹608
    1 619 PB3 823Reversing SwitchWear part1₹758
    Cover Disc1₹58
    1 619 PB3 824On-Off SwitchWear part1₹758
    Screw9₹77
    1 619 PB3 825Motor Protection SwitchWear part1₹1,213
    Cover Plate1₹290
    Laser unit1₹1,818
    Cover Plate1₹156
    Laser1₹1,471
    Cover Plate1₹58
    Hex Nut1₹77
    Rear Panel1₹284
    Washer1₹77
    Protective Cover1₹153
    Tag1₹77
    Light Unit1₹78
    Toothed lock washer1₹77
    Screw1₹77
    Screw9₹77
    1 619 PB4 099Cable ClipWear part1₹77
    1 619 PB4 100Cable HolderWear part1₹77
    Grommet1₹77
    Tapping Screw2₹73
    Round copper wire1₹77
    Round copper wire BLACK1₹58
    O-Ring1₹153
    Cover Plate1₹241
    Milling machine arbor1₹6,955
    Drift1₹368
    Reduction Sleeve1₹681
    Positioning Pin1₹271
    Safety rope1₹946
    Coolant Tank1₹1,905
    Tank Cover1₹153
    End Plug1₹78
    Mounting Bracket1₹824
    1 619 PB4 295Carbon-Brush SetWear part1₹511.5
    Intermediate Flange1₹1,515
    Gear Housing1₹5,973
    Toothed rack1₹2,273

    List prices are from the Bosch India spare parts price list 2026 and may change without notice. Call to confirm the price and stock before ordering.

    Questions

    Which power cord fits the Bosch GBM 50-2?

    Connector Cable, Bosch part number 1 619 PB4 148 (diagram item 40). List price ₹78.

    What is the field (stator) part number for the Bosch GBM 50-2?

    Field assembly 220V, Bosch part number 1 619 PB4 201 (diagram item 2). List price ₹3,501.

    What is the armature part number for the Bosch GBM 50-2?

    Armature assembly 220V, Bosch part number 1 619 PB3 666 (diagram item 3). List price ₹4,753.

    What is the gear set part number for the Bosch GBM 50-2?

    Toothed Gear, Bosch part number 1 619 PB3 652 (diagram item 53). List price ₹1,515.

    What is the electronics module part number for the Bosch GBM 50-2?

    Printed Circuit Board, Bosch part number 1 619 PB4 074 (diagram item 28). List price ₹3,023.

    What is the spindle part number for the Bosch GBM 50-2?

    Drilling Spindle, Bosch part number 1 619 PB3 639 (diagram item 66). List price ₹1,818.
