Bosch GDC 141 Marble Cutter spare parts

    Tool number 3 601 CA4 1F0 · 220 V

    Prices from the Bosch India Spare Parts Price List 2026 · Last updated

    Call +91 95123 49969WhatsApp a parts list

    Most replaced parts

    1 619 PB8 856

    ₹714

    Field

    1 619 PB7 282

    ₹521

    Gear Box

    1 619 PB5 623

    ₹152

    Switch

    1 619 PB7 280

    On request

    Power supply cord

    1 619 PB5 757

    ₹64

    groove ball bearing

    1 619 PB7 286

    ₹1,203

    Armature assembly

    1 619 PB5 915

    ₹94

    Carbon Brush

    1 619 PB7 287

    ₹553

    spindle assembly

    All parts

    ItemPart numberDescriptionQtyList price
    1 619 PB8 856FieldWear part1₹714
    1 619 PB7 282Gear BoxWear part1₹521
    1 619 PB5 623SwitchWear part1₹152
    Washer1₹32
    1 619 PB7 280Power supply cordWear part1On request
    Wing Screw1₹32
    1 619 PB5 767Cord guardWear part1₹32
    1 619 PB5 757groove ball bearingWear part1₹64
    1 619 PB5 768Cable ClipWear part1₹32
    Spring retaining ring1₹29
    Nameplate1On request
    1 619 PB7 284PinionWear part1₹96
    Capacitor1₹32
    bushing1₹29
    1 619 PB5 758groove ball bearingWear part1₹54
    Spring retaining ring1₹29
    1 619 PB5 759groove ball bearingWear part1₹98
    Washer1₹29
    Screw2₹32
    1 619 PB5 760groove ball bearingWear part1₹172
    Air-Deflector Ring1₹32
    Upper guard1₹60
    Screw2₹32
    Screw2₹31
    Handle1₹113
    Output Shaft1₹107
    Cap1₹164
    Woodruff Key1₹29
    Screw4₹32
    Rubber Ring1₹29
    Screw3₹32
    Clamping Flange1₹32
    Cap1₹32
    Clamping Flange1₹39
    Insulating Cap2₹32
    Bolt1₹32
    1 619 PB5 775Bearing SleeveWear part1₹32
    Base1₹278
    Rubber Ring1₹29
    Slotted Spring Pin1₹32
    Washer1₹29
    Spanner1₹45
    Rectangular Ring1₹39
    Socket Wrench1₹72
    1 619 PB7 283GearWear part1₹82
    Housing Set1₹441
    Hex Nut1₹29
    1 619 PB7 286Armature assemblyWear part1₹1,203
    1 619 PB9 160Armature assemblyWear part1₹769
    1 619 PB5 915Carbon BrushWear part1₹94
    1 619 PB7 287spindle assemblyWear part1₹553

    List prices are from the Bosch India spare parts price list 2026 and may change without notice. Call to confirm the price and stock before ordering.

    Questions

    What is the field (stator) part number for the Bosch GDC 141?

    Field, Bosch part number 1 619 PB8 856 (diagram item 2). List price ₹714.

    What is the gear set part number for the Bosch GDC 141?

    Gear Box, Bosch part number 1 619 PB7 282 (diagram item 38). List price ₹521.

    What is the switch part number for the Bosch GDC 141?

    Switch, Bosch part number 1 619 PB5 623 (diagram item 4). List price ₹152.

    Which power cord fits the Bosch GDC 141?

    Power supply cord, Bosch part number 1 619 PB7 280 (diagram item 5).

    Which bearings does the Bosch GDC 141 use?

    groove ball bearing, Bosch part number 1 619 PB5 757 (diagram item 41). List price ₹64.

    What is the armature part number for the Bosch GDC 141?

    Armature assembly, Bosch part number 1 619 PB7 286 (diagram item 803). List price ₹1,203.
