Bosch GTS 254 Table Saw spare parts

    Tool number 3 601 M45 0F0 · 230 V

    Prices from the Bosch India Spare Parts Price List 2026 · Last updated

    Call +91 95123 49969WhatsApp a parts list

    Most replaced parts

    1 604 220 58V

    ₹2,170

    Field

    1 607 200 37L

    ₹940

    Switch

    1 619 PB6 262

    On request

    Power Cable IND

    1 600 900 09G

    ₹244

    groove ball bearing

    1 600 A02 2BL

    ₹830

    Crown Gear

    1 619 PB6 280

    ₹327

    Carbon-Brush Set

    All parts

    ItemPart numberDescriptionQtyList price
    1 604 220 58VFieldWear part1₹2,170
    Plate1₹32
    1 607 200 37LSwitchWear part1₹940
    Screw1₹32
    1 619 PB6 262Power Cable INDWear part1On request
    Locking Lever1₹147
    Grommet1₹32
    Guard1₹293
    Clamp2₹32
    Riving Knife1₹379
    Nameplate1On request
    Bolt1₹45
    Sticker1On request
    Stop Plate1₹41
    Suppression Capacitor1₹195
    Stop Plate1₹43
    1 600 900 09Ggroove ball bearingWear part1₹244
    Insert1₹554
    Screw10₹32
    Clip1₹140
    Nut3₹32
    Screw1₹32
    Plug1₹32
    Cover1₹32
    End stop1₹459
    Table top1₹901
    Bolt2₹32
    Base1₹336
    Plug1₹32
    Screw4₹32
    Knob4₹32
    Plug1₹32
    Screw6₹32
    Screw13₹32
    Locking Pin1₹46
    Table top1₹4,654
    Clamping Lever1₹89
    Handle2₹45
    Wheel1₹32
    Seat1₹234
    Gasket22₹32
    Screw4₹32
    Screw5₹40
    Seat2₹49
    Bracket1₹78
    Screw6₹32
    Screw2₹32
    Torsion Spring1₹32
    Guard1₹216
    Output Shaft1₹205
    Guard1₹32
    Screw1₹32
    Shim2₹32
    1 600 A02 2BLCrown GearWear part1₹830
    Seat1₹296
    Riving Knife1₹65
    Nut34₹32
    Circlip1₹32
    Spring Washer24₹32
    Screw2₹32
    Washer30₹31
    Seat1₹327
    Scale Wheel4₹32
    pad1₹32
    Indicator1₹32
    Seat1₹152
    mounting plate4₹32
    Plate1₹1,348
    Bolt4₹32
    Nut1₹75
    Plug1₹32
    Screw4₹32
    Scale1₹76
    Screw2₹32
    Base1₹930
    Washer1₹32
    Scale1₹46
    Cap2₹32
    Plug1₹32
    Cover1₹72
    Gasket4₹32
    Connecting Wire1₹95
    Cover1₹554
    Washer2₹32
    Screw1₹75
    Screw2₹32
    Flange1₹76
    Sleeve1₹31
    Flange1₹194
    Rod1₹261
    Plate1₹79
    1 606 333 2FFBevel GearWear part2₹184
    Screw4₹32
    Screw2₹32
    Woodruff Key1₹32
    Sleeve1₹32
    Washer1₹32
    Screw1₹32
    Equipment Holder1₹87
    Nut1₹60
    Seat2₹32
    Washer1₹49
    Body1₹3,240
    Pointer1₹32
    1 604 400 01PCableWear part1₹41
    Shaft1₹130
    Protection1₹195
    Screw5₹32
    Screw3₹32
    Rod1₹204
    Bracket1₹32
    Sleeve1₹31
    Seat1₹191
    Plate1₹120
    1 600 A02 2D6Switch CoverWear part1₹51
    Seat1₹146
    Pin1₹32
    Screw4₹32
    1 600 A02 2C4Switch SpringWear part1₹32
    Plug1₹32
    Trigger1₹49
    Plate1₹152
    Screw3₹32
    Plug1₹32
    Plate1₹446
    Screw2₹32
    Nut2₹32
    Frame4₹917
    Nut3₹32
    Supporting foot4₹32
    Cap1₹32
    Support2₹293
    Handle1₹46
    Screw4₹32
    Screw1₹32
    Screw8₹32
    Wheel1₹94
    Table Leg4₹2,081
    Washer2₹32
    Screw8₹32
    Spring1₹32
    Push rod1₹91
    Lever1₹66
    Gripping Wedge1₹72
    Assembly Wrench1₹78
    Screw1₹32
    Spring1₹32
    Inductor1₹97
    Tube3₹58
    Motor Housing1₹749
    1 619 PB6 280Carbon-Brush SetWear part1₹327
    1 619 PB6 276Bearing coverWear part1₹249
    Gear Housing1₹716
    Edge Guide1₹2,317
    Pawl1₹496
    Mitre Fence1₹718

    List prices are from the Bosch India spare parts price list 2026 and may change without notice. Call to confirm the price and stock before ordering.

    Questions

    What is the field (stator) part number for the Bosch GTS 254?

    Field, Bosch part number 1 604 220 58V (diagram item 2). List price ₹2,170.

    What is the switch part number for the Bosch GTS 254?

    Switch, Bosch part number 1 607 200 37L (diagram item 4). List price ₹940.

    Which power cord fits the Bosch GTS 254?

    Power Cable IND, Bosch part number 1 619 PB6 262 (diagram item 5).

    Which bearings does the Bosch GTS 254 use?

    groove ball bearing, Bosch part number 1 600 900 09G (diagram item 13). List price ₹244.

    What is the gear set part number for the Bosch GTS 254?

    Crown Gear, Bosch part number 1 600 A02 2BL (diagram item 115). List price ₹830.

    Which carbon brushes fit the Bosch GTS 254?

    Carbon-Brush Set, Bosch part number 1 619 PB6 280 (diagram item 810). List price ₹327.
